Description
Unleash your creativity on an epic scale with the Uniformation GK3 ULTRA, the 16K SLA Resin Printer designed for creators who think big. Forget the limitations of standard printers; the GK3 ULTRA combines a massive build volume with a groundbreaking 16K resolution to deliver high-quality, large-format prints with unprecedented ease and speed.
Experience True 16K Detail on a Colossal Scale
The GK3 ULTRA is not just big—it's brilliant. Its stunning 13.5" monochrome LCD screen boasts a true 16K resolution of pixels, delivering a remarkable XY resolution of µm. This is the new standard for large-format resin printing, allowing you to produce breathtakingly intricate models and prototypes. The Uniformation-designed COB light source and Fresnel lens system ensure uniform UV light distribution, guaranteeing that every corner of your print is as sharp and flawless as the center.
Designed for High Throughput and Unrivaled Convenience
Stop babysitting your prints. The GK3 ULTRA is engineered for efficiency and convenience, enabling you to print large parts or entire batches of models with minimal effort. Its intelligent, automatic resin feeding system keeps the vat consistently filled, eliminating mid-print interruptions and the risk of failed prints due to a lack of resin. Paired with a smart heating system that automatically maintains the optimal resin temperature, the GK3 ULTRA ensures a high success rate, regardless of ambient conditions.
Built to Last, Crafted for Simplicity
This printer's heavy-duty construction, featuring a dual-rail, dual-ball screw Z-axis, provides industrial-grade stability.This robust design virtually eliminates Z-wobble and ensures pinpoint accuracy on every layer, even during the fastest print cycles. The quick-release build plate and resin vat, along with a thoughtfully designed resin drip hanger, make post-processing a clean and simple task. With the GK3 ULTRA, you get a powerful, reliable machine that's as easy to use as it is effective.
Don't settle for less. The Uniformation GK3 ULTRA is the ultimate tool for hobbyists and professionals ready to take their resin printing to the next level. Its unique combination of huge build volume, stunning 16K resolution, and intelligent, user-friendly features makes it the smartest choice for anyone serious about creating exceptional 3D models.
| Product name | GK3 ultra | Layer thickness | 0.03mm–0.05mm |
|---|---|---|---|
| Touch screen | 5-inch capacitive touch screen | Exposure speed | 2–3s/layer (0.05mm) |
| Slicing software | UniFormation Slicer, Chitubox, Lychee | Pixel size | 20×26μm (AVC 26μm) |
| Connection | USB stick, WiFi file sharing, Ethernet | Product dimensions | 455×400×575(mm) |
| Technology | Masked SLA (M-SLA) LCD Screen Curing | Maximum print volume | 300×160×300(mm) |
| Screen size | 302.4×161.98mm (16K 13.5″) | Official resin compatibility | Standard Resin (Black, White, Grey, Clear, Orange, Dark Grey, Red Wax) ABS Resin (Black, White, Grey, Clear, Clear Blue) Flexible Resin (Black, White) Water Washable Resin |
| XY resolution | 15120×6230 | Resin box capacity | 1.2kg |
| Maximum heating temperature | 25℃, 30℃ | Resin vat capacity | 1100ml |
| Product weight | 30KG | Printing power consumption | 200W |
