West3D Voron Trident Self-Source Configurator

West3D PrintingSKU: TridentConfig

Price:
Sale price$1,300.00

Customer Reviews

Based on 1 review
100%
(1)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
M
Mark
Great way to build a printer that is customized but comes in a kit

I used this to build my first printer coming from 2 creality printers. I highly recommend this method if you want some options that are not in the more stock kits available here. I was able to build a 350 Trident when it wasnt offered in a prebuilt kit this way. Multiple West3d employees put up with a lot of questions and pointed me in the right direction with the build. I would not hesitate to use this tool again for a large build

Description

Please read the full description before making a purchase!
Want to build a Voron, but get rid of all that messy sourcing work? We've done it for you, here is our version of the 'easy button'. We've put together what we feel is a good quality default 'kit' but left the benefits of self-sourcing intact so you can make the Voron that is the best fit for you. This configurator gives you the benefit of a large order discount, saves you sourcing 'screen-time', and the benefit of working with a US based source who can provide prompt support.

We are moving away from calling this a 'kit' for now as we believe this gives you freedom to choose your own destiny. With that to be successful at building a Voron using this configurator you will require working knowledge of 3D Printers, electronics, wiring/crimping, coding and have patience (amongst I'm sure other things.) If you choose our standard harness you will have to do some crimping still, we provide some connectors free to assist but if you need additional ones you will want to make sure you have those.

If there are configurations you'd like to see added please let us know (info@west3d.com).

Please note:

We are stocking up on products to provide a steady supply, but at times we will not have all the components in warehouse and will be waiting on shipment before your order can ship out. Because of this, currently we are offering this on a 'pre-sale' basis. In some instances we will ship partial kit orders to allow you to begin your build while you wait (e.g. frame+fasteners+motion). While we try to quickly restock, given current popularity and logistical constraints we ask you to please expect roughly 4 weeks for shipment, though this is not a guarantee. Pre-sales are refundable up until the date of shipment less a 3.5% transaction fee (the approximate cost we incur). Configurator orders are no eligible for additional promotional offers.

This BOM in a box does not include:

1. Raspberry Pi (though we do offer a MantaM8P and CB1 as an offering)

2. Micro-SD Card

3. Loctite

4. Cat6 Keystone

 Kit is default set up for Stealthburner toolhead, if selecting a Slice hot end please note official support has ended. We can build this for afterburner and CW1. You may also select LDO's V1/2 high temp motor kit which will default for CW1.

Removing the hot-end means you will not receive a heater cartridge and thermistor, if you need those please add them manual from our product listings.



If you have questions or wish to get an estimate of current timelines please email us at info@west3d.com or message us on the #west3d channel on the Voron Discord Server. The below attempts

WEST3D Trident - BOM In a Box
Description Quantity Configurable Config 1 Config 2 Config 3 Config 4
Printed Parts 0 YES Printed Parts
West3D BDF Stainless Steel Fasteners - Default 1 YES West3D BDF All Black
West3D Motion Kit Silver 1 YES West3D Motion Kit Black POWGE Motion Silver Berserker Trident Motion Kit
West3D Custom MGN9 Rails 5 YES LDO MGN9 Rails West3D MGN9 Black BerserkerMGN9 Rails
West3D Custom MGN12 Rails 1 YES LDO MGN12 Rails West3D MGN12 Black BerserkerMGN12 Rails
Updated Rubber Feet for Trident 4 NO
Z PCB 1 YES Sexbolt Microswitch
XY Microswitch PCB
1 YES Microswitches Hall Effect PCB
Omron TL-Q5MC2-Z NPN Inductve Probe 1 NO Klicky Probe (Complete)

PCB Klicky Probe Kit

TAP
Bat85 Diode 1 NO
Panasonic AWA211VL 15A SSR 1 YES Omron G3NA-210B-DC5 10A SSR
Beast Mode High Temperature Motor Kit (LDO 42STH48-2504MAH x2 + LDO 36TH20-1004ASH (SB) + LDO Teflon Coated Lead Screw Z Motors 1 YES LDO High Temp Motor Kit (Clockwork 1) (1 x LDO-42STH20-1004ASH(VRN) 2 x LDO-42STH48-2004MAH(VRN)) + LDO Teflon Coated Lead Screw Z Motors
Mean Well LRS-200-24 200W 24V 8.8A Power Supply (PSU) 1 NO Mean Well LRS-200-48 Mean Well UHP-200-24 Mean Well UHP-200-48
Mean Well RS-25-5 25W Power Supply (PSU)
1 NO
ZF - Rocker Switch DPST 16A On-Off - WRG32F2BBRLN 1 YES AC Power Unfiltered Inlet w/ 15A switch 250VAC Inlet IEC-GS-1-100 - Adam Tech
TycoElectronics - 10EHG1-2 Filtered Power Inlet 1
Fuse 8A 250V Holder Cartridge 5 X 20mm Glass
3 NO
GDSTIME DC 24V 40x40x10 Axial Fan GDA4010 1 YES Sunon 4010 Premium MagLev Axial
GDSTIME DC 24V 50x50x15 Centrifugal Blower Fan GDB4020 1 YES Delta 5015 BFB0524HH DC 24 0.16A 2 Pin Cooling Fan
GDSTIME DC 24V 60x60x20 Axial Fan GDA6020 Dual Ball Bearing 5000RPM 1.7W 0.1A XH2.54 3 NO
125C Cutoff 15A Thermal Fuse 1 NO
BTT Octopus Controller Board / 3D Printer Control System 1 YES Octopus PRO 446 Octopus PRO 429 Makerbase Monster8 FYSETC Spider Manta M8P + CB1 + CB1 Heatsink
TMC2209 Stepper Motor Driver / Drivers (BTT) 7 YES TMC2226 5160HV
Mini 12864 Display Type B RGB - Choose your color 1 YES PTFT43 PTFT50 PTFT70
Voron Trident USA Frame Kit (Silver or Black) 1 YES LDO Trident Frame Kit (Red, Space Grey, or Blue)
Bowden / PTFE Tube 4mm OD 3mm ID 3 NO
6mm x 3mm Round Neomydium Magnets 8 NO
Bowden Coupler for 4mm OD PTFE Tube 1 NO
5mm x 10m Single Sided Self Adhesive Tape / 1mm thick 1 NO
BMG Components Kit by TriangleLab Hardened Steel 1 YES BMG Components Kit Nano Coated RNC Orbiter 2.0
Wiring Harness for Voron 2.4 / Trident 1 YES Linneo DIY FEP Wiring Harness GleipnerHarness
Generic Cable Chain Set for Trident  1 YES IGUS Cable Chain Set
Mandala Roseworks ABS Panels Black  1 YES Mandala Roseworks ABS Panels White  Trident ACM Panels Trident ACM Panels + Custom Etch
Mandala Roseworks Acrylic Panels Clear 1 YES Mandala Roseworks Acrylic Panels Smoked
Voron Trident Build MIC6 Aluminum Build Plate 1 YES Mandala Roseworks Ultraflat Magbed
Keenovo Silicone Heater / Heating Pad 1 NO
Magnetic Flex Plate Double-Sided (Texture - Smooth) with 3M Magnetic Backing (Energetic & West3D Collab) 1 YES West3D High Performance Black PEI Bed Flex Plate with High-Temp Mangnetic Backing (multiple finish options)
TriangleLab/ Phaetus Rapido HF 1 YES Many options available, see configuration menu
50W 24V Heater Cartridge with 100CM cable 1 YES 50W Heater Cartidge - 24V Slice Engineering
PT1000 Thermistor Cartridge (450C) 1 YES Pt1000 Resistance Temperature Detector (RTD) Thermistor Thermistor High Temperature - 300C E3D 104NT      Thermistor
Mobil Mobilux EP2 10ml filled syringe with blunt tips 1 NO
Large Printed Parts Decal 1 NO
Voron Design Decal 1 NO
Din Rails (Pair) 1 NO
Din Clamp 1 NO
Wire Connectors 3 NO
Wire Connectors DIN 2 NO
ADXL345 1 NO
C13 Power Cord 1 NO
ZipTies, VHB Tape + Other Misc. 1 NO
