Description
This filament is highly abrasive, we strongly recommend printing with Tungsten Carbide Nozzle like the Undertaker
Ambrosia Filament's line of Polycarbonate Carbon Fiber blend of filament is designed to be printable without sacrifice. Manufactured to a tighter than standard tolerance (+/- 0.03mm) you'll experience consistent extrusion throughout the spool.
Polycarbonate filament requires a heated bed, chamber and printing at higher temperatures than other common filaments.
Feed your Printer the Filament of the Gods.
PCCF (polycarbonate + carbon fiber) combines advantages of PC filament with easier printing. This filament includes a blend of approximately 10% PETG to promote a better printing experience without sacrificing the properties of PC or CF. The filament both provides better heat resistance, strength and toughness than ABS or other common filaments with printability only being marginally tougher.
- Arrives to you in a cardboard box, with filament wound in a cardboard spool, vacuum sealed with a desiccant bag.
- Diameter: 1.75mm (+/-0.03mm)
- Filament Net Weight: 1KG
- Spool Weight:
The glue holding the filament spool together is rated for an environment of 70C (158F). If using a filament dryer or require the filament spool by placed in an environment exceeding this temperature, we recommend printing a spool clip (Here).
Check out our other lines of Ambrosia Filament!
| ASA | ASA-CF | ASA Sparkle | ASA Dolos | ABS+ | PETG | PLA |
| PC-ABS | PC-CF | TPU | ABS Matte | ASA-GF |
Ambrosia Filament's Recommended Print Settings for our PC-CF filament:
| Attribute | Accepted Value(s) [Our Recommended Value] |
| Extruder Temperature | 250-290 Degrees Celsius [270] |
| Heated Bed | 100-115 Degrees Celsius [110] |
| Build Surface | PEA, PEI, Buildtak, or similar surface [Smooth PEI or PEA with adhesive] |
| Cooling Fan | 0-70% range varies by cooling capabilities |
| Environmental Temperatures | 40-120C [60C] |
| Soluble Support Materials | HIPS or other Water Soluble Support Material |
Technical Specifications for our PCCF Filament:
| Physical Properties | Test Methodology | Values |
| Density | ISO1183 | TBD |
| Melt Flow Rate (250C/2.16KG) | ISO 1133 | TBD |
| Moisture Absorption (23C/24h) | ISO 62 | TBD |
| Mechanical Properties | Test Methodology | Values |
| Tensile Strength | ISO 527 | TBD |
| Elongation at break | ISO 527 | TBD |
| Flexural Modulus | ISO 527 | TBD |
| Flexural Strength | ISO 178 | TBD |
| Impact Strength | ISO 180 | TBD |
| Thermal Dynamic Properties | Test Methodology | Values |
| HDT@ 0.455 MPa(66 psi) | ISO 75 | TBD |
Filament can absorb moisture easily. To prevent moisture absorption and contamination, the packing of filament should be kept sealed and in an airtight container with desiccant.
