Description
Ambrosia Filament's line of Polycarbonate blend filament are designed to be printable without sacrifice. Manufactured to a tighter than standard tolerance (+/- 0.03mm) you'll experience consistent extrusion throughout the spool.
Polycarbonate filament requires a heated bed, chamber and printing at higher temperatures than other common filaments.
Feed your Printer the Filament of the Gods.
PC-ABS (polycarbonate + acrylonitrile butadiene styrene) combines advantages of PC filament with easier printing. The filament both provides better mechanical properties and heat resistance than ABS with printability only marginally tougher.
- Arrives to you in a cardboard box, with filament wound in a cardboard spool, vacuum sealed with a desiccant bag.
- Derived from 100% Virgin (Grade-A) non-toxic pellets
- Diameter: 1.75mm (+/-0.03mm)
- Filament Net Weight: 1KG
- Spool Weight:
The glue holding the filament spool together is rated for an environment of 70C (158F). If using a filament dryer or require the filament spool by placed in an environment exceeding this temperature, we recommend printing a spool clip (Here).
Check out our other lines of Ambrosia Filament!
| ASA | ASA-CF | ASA Sparkle | ASA Dolos | ABS+ | PETG | PLA |
| PC-ABS | PC-CF | TPU | ABS Matte | ASA-GF |
Ambrosia Filament's Recommended Print Settings for our PC-ABS filament:
| Attribute | Accepted Value(s) [Our Recommended Value] |
| Extruder Temperature | 250-280 Degrees Celsius [270] |
| Heated Bed | 100-115 Degrees Celsius [110] |
| Build Surface | PEA, PEI, Buildtak, or similar surface [Smooth PEI or PEA with adhesive] |
| Cooling Fan | 0-70% range varies by cooling capabilities |
| Environmental Temperatures | 40-120C [60C] |
| Soluble Support Materials | HIPS or other Water Soluble Support Material |
Technical Specifications for our PC-ABS Filament:
| Physical Properties | Test Methodology | Values |
| Density | ISO1183 | 1.14-1.15g/cm3 |
| Melt Flow Rate (250C/2.16KG) | ISO 1133 | 19-22g/10min |
| Moisture Absorption (23C/24h) | ISO 62 | <0.8% |
| Mechanical Properties | Test Methodology | Values |
| Tensile Strength | ISO 527 | 43.5-45.5 |
| Elongation at break | ISO 527 | 24-26% |
| Flexural Modulus | ISO 527 | 800-950Mpa |
| Flexural Strength | ISO 178 | 71.5-74.5Mpa |
| Impact Strength | ISO 180 | 43.5-44.5KJ/m2 |
| Thermal Dynamic Properties | Test Methodology | Values |
| HDT@ 0.455 MPa(66 psi) | ISO 75 | 123C |
Filament can absorb moisture easily. To prevent moisture absorption and contamination, the packing of filament should be kept sealed and in an airtight container with desiccant.
